Quality Home Theater Is Now Within Your Reach

Targeting the sweet spot where affordability meets superb functionality, the TX-NR609 looks set to be another Onkyo classic. This THX® Select2 Plus™ Certified A/V receiver handles content from all your favorite disc-based media, as well as networked audio content from the internet, iPod®/iPhone®, and PC. Six HDMI® inputs—including one on the front panel—provide support for 3D video and ultra-high resolution 4K video upscaling via Marvell Qdeo™. HDMI also carries master-quality audio formats from Dolby and DTS, as well as the expanded surround sound of Audyssey DSX™ and Dolby® Pro Logic® IIz. Three-stage inverted Darlington circuitry and Onkyo’s proprietary WRAT ensure a clean and compelling amplifier performance. And when audio signals are output, the 7.2-channel configuration includes twin subwoofer pre-outs for added bass impact. Meanwhile, a user-friendly on-screen display and GUI make it easy to adjust settings and navigate your content. All this and more makes the TX-NR609 an irresistible choice for the value-seeking home theater fan.

*Sold exclusively within the US only. No shipments allowed outside the US!

2011 Onkyo AV Receiver Comparison Chart

Special Features

• HDMI Support for 3D Video and Audio Return Channel
• Marvell Qdeo™ Video Chip for 4K Upscaling and Processing
• Network Capability Delivers Internet Radio and Network Streaming
• THX® Select2 Plus™ Certified
• Direct Digital Connection of iPod/iPhone via Front-Panel USB Port
• Audyssey DSX™ and Dolby® Pro Logic® IIz Add New Dimensions to Surround Sound

Amplifier
# Channels	7.2
Power (8ohms 20-20kHz, 0.08%, 2 Channels Driven, FTC) /CH	100W
Power (8ohms 20-20kHz 0.05%) /Ch	-
THX Certified
Continuous 6ohms Rated
Certified 4ohms performance	-
All Discrete Circuitry
3-Stage Inverted Darlington Circuitry
PUSH-PULL Design	-
Independent Block Construction (Amp/Preprocessor)	-
Toroidal Transformer	-
Independent Power Supply	-
Bi-amp Capability For Front	-
BTL Capability For Front	-
Processing
DOLBY Decoder	True HD, DD Plus, PLIIz
DTS Decoder	DTS-HD Master Audio
Dolby PLIIz
ONKYO GAME Surround Modes
DTS Surround Sensation Speaker / Headphone	- / -
Neural Surround	-
THX Processing Mode
Audyssey DSX
Audyssey Dynamic EQ
Audyssey Dynamic Volume
Direct/Pure Mode	/ -
Music Optimizer	(Advanced)
192K/24 Bit DACs	(Burr-Brown)
VLSC	-
isf Certified Calibration Control	-
Connectivity
Audio I/O	7 / 2
Phono Input	-
Digital Audio IN (OPT/COAX)	2 / 2
Digital Audio OUT (OPT/COAX)	-
Composite I/O	5 / 1
S-Video I/O	- / -
Component Video I/O	2 / 1
Front-Panel A/V	V
Front-Panel Optical	-
HDMI I/O	6 (5 + 1)/ 1
HDMI Version	V1.4a (supports 3D video and Audio Return Channel)
Component Video Upconversion	-
Analog To HDMI UpConversion
1080p Upscaling	(Marvell Qdeo)
4K (3840 x 2160) Upscaling	(Marvell Qdeo)
Multi-Channel Input	-
Analog Pre-Outs	Sub
Speaker A/+B	-
Powered Zone2
Zone 2 Line Out
Zone 2 Video Out	-
Zone 3 Line Out	-
U-Port
iPod Ready	(direct USB input, optional UP-A1)
HD Radio Ready	(optional UP-HT1)
Internet Radio Capable
vTuner, Pandora, Rhapsody, Sirius/XM iRadio
Slacker, Mediafly, Napster iRadio
Streaming Audio From PC
Streaming Audio From USB memory
PC Input (15 pin D-sub)
Integration Access
RS-232	-
IR Input	-
Ethernet
ONKYO-RI System Control
12V Trigger	-
Miscellaneous
Pre-Pro/Learning Remote	/ -
Back-Lit Remote	-
On Screen Remote Programming	-
Bi-directional Remote Setup via GUI	-
Activity Based Remote	-
Color-Coded Speaker Terminals
Auto Speaker Calibration W/Mic.	(Audyssey 2EQ)
OSD Out	(advanced "Home" GUI)
Solid Aluminum Front
