ONKYO TX-NR616 7.2-Ch THX Certified Network A/V Receiver

ONKYO TX-NR616 7.2-Ch THX Certified Network A/V Receiver

Item #: ONKTXNR616
Availability: IN STOCK, ships out in 1-2 Business Days.
57% off
Click for the BBB Business Review of this Electronic Equipment & Supplies - Dealers in Apopka FL
Item Condition:
Onkyo Factory Refurbished
Manufacturers Warranty:
1 Year
Included Accessories:
Remote Control, Manual, AM/FM Antenna, Setup Microphone
Manufacturers Part #:
Ask an expert Accessories4Less advisor



Escape into THX®-Certified Surround Sound

Movie, music, and gaming enthusiasts can now step up to realistic THX® Select2 Plus-certified surround sound for less money down with the new TX-NR616 Network A/V Receiver. Onkyo's acclaimed WRAT amplifier with three-stage inverted Darlington circuitry delivers cinema-like power in the home. With Audyssey DSX expansion, you can add extra Wide or Height channels for more enveloping surround sound, while 2EQ acoustic correction guarantees optimal performance in any room. Eight HDMI® inputs handle 3D content, HD audio, and video display upscaled to 4K with onboard Qdeo technology. The MHL/HDMI input lets you connect a smart phone for smooth 1080p playback on your TV. Wireless home networking, meanwhile, opens up an exciting world of internet radio and cloud-based music streaming. You can even enjoy your multi-format PC-based music collection over Wi-Fi with an optional USB adapter. Intuitive system control- including audio distribution in multiple rooms- is provided by Onkyo's remote apps for iPod® touch/ iPhone®, Android phone, and Kindle Fire, or press the Quick Set-Up button on the supplied remote for instant mid-program adjustments. Visual input selection with InstaPrevue technology rounds out what is an exceptionally refined and affordable THX receiver.

*Sold exclusively within the US only. No shipments allowed outside the US!

Hear Precisely What The Director Intended

THX ensures what you hear through this Onkyo is precisely what was recorded. Select2 Plus certification is specified for rooms where the screen-to-seat viewing distance is ten to twelve feet, and the room volume is around 2000 cubic feet. To achieve THX certification, the TX-NR616 had to meet the most demanding standards for home cinema audio quality and performance.

Access Endless Music Possibilities

Onkyo network receivers, which are also wireless LAN ready, have access to the most internet music content services, including: Pandora®, Slacker, SIRIUS XM®,, vTuner, Rhapsody, Spotify, and AUPEO!. You can even connect to DLNA servers on your network. Internet connectivity also makes firmware updates simpler than ever.

Easy, Live Source Selection

This AVR incorporates InstaPrevue visual port management technology, making input source selection much easier. InstaPrevue provides a live video thumbnail of the available content on your devices connected via HDMI. You no longer have to remember that your gaming console is connected to Port 3, or your BD player to Port 1, for example- you can see what's playing and choose accordingly.

Watch Your Smartphone Content on TV

The front-panel HDMI port is designed for the connection of mobile phones and other portable electronic devices using the new MHL standard. MHL allows you to display full 1080p video and still images on your HDTV with up to 7.1 channels of surround sound. Use the receiver's remote to control playback from your phone as it receives a handy recharge.

Free Apps: Seamless Control & Streaming

The Onkyo Remote App 2 for iPod touch/iPhone and Onkyo Remote for Android and Kindle Fire provide an intuitive way to operate Onkyo network A/V receivers. Control input sources, adjust settings, and play audio stored in your device wirelessly (Android and Kindle Fire only) using the application's interactive graphical display. The remote apps are available separately as free downloads.

Direct Digital Connection: The Cleanest Your iPod Can Sound

The front-panel USB port lets you play MP3 and AAC stored in an iPod/iPhone, and MP3, WMA, AAC, and FLAC audio files stored on a flash-memory device, and you can use the system's own remote for track selection and playback. Your music will sound much cleaner and clearer, as the audio signal is transported in digital rather than analog form through the direct digital connection.

The Onkyo remote is preset to control Apple TV

Have an Apple TV? Use it with your Onkyo Network AVR. It's all integrated; it all works together beautifully.

Audyssey Room Correction: You'll Hear The Difference

(1) Audyssey 2EQ tailors multi-channel audio for your home theater speaker set-up by measuring three room positions and applying a resolution filter to the satellite speakers to correct for room acoustics.
(2) Audyssey Dynamic EQ® maintains a consistent bass response, tonal balance, and surround-sound effect at different volume levels, so you can enjoy the natural dynamics of your content regardless of the volume.
(3) Audyssey Dynamic Volume® automatically compensates for volume fluctuations in different audio content-for example, during commercial breaks-while optimizing the dynamic range

4k Upscaling: Astoundingly Accurate Detail

On a compatible 4K wide-screen display, this receiver will upscale standard video sources, making your Blu-rays and DVDs pop with more cinematic detail than ever before. The versatile Qdeo video processor uses algorithms to enlarge to 4k the video you're playing, while also erasing video jaggies and feathering. The results are dazzlingly detailed images.

Save Power With Hybrid Standby

Hybrid Standby provides 'HDMI through' functionality while the receiver sleeps, so you don't have to fully power up to watch a Blu-ray or play a game using just your TV's sound. The receiver also maintains a local network connection when on Hybrid Standby mode, so you can switch the unit on at any time using the Onkyo remote apps for iPod touch/iPhone, Android, and Kindle Fire.


# Channels


Power Watts/ch

100W (8ohms 20-20kHz, 0.08%, 2 Channels Driven, FTC)

THX Certified

Select2 Plus

Continuous 6ohms Rated

All Discrete Circuitry


DOLBY Decoder

True HD, DD Plus, PLIIz

DTS Decoder

DTS-HD Master Audio

Dolby PLIIz

ONKYO GAME Surround Modes

Audyssey DSX

✓ (height only)

Audyssey Dynamic EQ

Audyssey Dynamic Volume

Direct/Pure Mode

- / ✓

Music Optimizer

✓ (Advanced)

192K/24 Bit DACs

✓ (Burr-Brown)


Audio I/O

5 / 2

Digital Audio IN (OPT/COAX)

2 / 2

Composite I/O

5 / 1

Component Video I/O

1 / 1

Front-Panel A/V


USB Input

Front (made for iPod/iPhone) and Rear


8 (7 + 1)/ 2

HDMI Version

V1.4a (supports 3D video and Audio Return Channel)

Analog To HDMI Upconversion

1080p Upscaling

✓ (Marvell Qdeo)

4K (up to 4096 x 2160) Upscaling

✓ (Marvell Qdeo)

Analog Pre-Outs


Powered Zone2

Zone 2 Line Out

Zone 3 Line Out

iPod Ready

✓ (direct USB input)

HD Radio Ready


Internet Radio Capable

✓ (vTuner, Pandora, Spotify, Aupeo, Rhapsody, Sirius/XM iRadio, Slacker, LastFM iRadio, MP3tunes cloud service

Streaming Audio From PC

Streaming Audio From USB memory

Wireless Network Ready via USB

✓ (optional UWF-1)

Integration Access


ONKYO-RI System Control


Pre-Pro/Learning Remote

- / ✓

On Screen Remote Programming

Color-Coded Speaker Terminals

Auto Speaker Calibration W/Mic.

✓ (Audyssey 2EQ)


✓ (advanced "Home" GUI)




Amplifier Section


Power Output


     All Channels

115 W (6 ohms, 1 kHz,
0.7%, 2 channels driven)

     Front L/R

100 W (8 ohms, 20 Hz-20 kHz,
0.7%, 2 channels driven, FTC)
125 W + 125 W (6 ohms, 1 kHz, 0.1%,
2 channels driven, FTC)


100 W (8 ohms, 20 Hz-20 kHz,
0.7%, 2 channels driven, FTC)
125 W (6 ohms, 1 kHz, 0.1%,
2 channels driven, FTC)

     Surround L/R

100 W (8 ohms, 20 Hz-20 kHz,
0.7%, 2 channels driven, FTC)
125 W + 125 W (6 ohms, 1 kHz, 0.1%,
2 channels driven, FTC)

     Surround Back L/R

100 W (8 ohms, 20 Hz-20 kHz,
0.7%, 2 channels driven, FTC)
125 W + 125 W (6 ohms, 1 kHz, 0.1%,
2 channels driven, FTC)

Dynamic Power

240 W (3 ohms, 1 ch)
210 W (4 ohms, 1 ch)
120 W (8 ohms, 1 ch)

THD+N (Total Harmonic Distortion + Noise)

0.08% (20 Hz-20 kHz, Half power)

Damping Factor

60 (Front, 1 kHz, 8 ohms)

Input Sensitivity and Impedance

200 mV/47 k-ohms (Line)

Output Level and Impedance

200 mV/2.2 k-ohms (Rec out)

Phono Overload


Frequency Response

5 Hz-100 kHz/+1 dB, -3 dB (DSP bypass)

Tone Control

±10 dB, 50 Hz (Bass)
±10 dB, 20 kHz (Treble)

Signal-to-Noise Ratio

106 dB (Line, IHF-A)

Speaker Impedance

6 ohms–16 ohms

Video Section


Input Sensitivity/Output Level and Impedance



1 Vp-p/75 ohms (Component)
0.7 Vp-p/75 ohms (Component PB/CB, PR/CR)
1 Vp-p/75 ohms (Composite)

Component Video Frequency Response

5 Hz–100 MHz, -3dB

Tuner Section


Tuning Frequency Range



87.5 MHz–107.9 MHz


530 kHz–1,710 kHz

FM/AM Preset Memory

40 stations



Power Supply

AC 120 V, 60 Hz

Power Consumption


Standby Power Consumption


Dimensions (W x H x D)

17 1/8" x 6 13/16" x 12 15/16" (435 x 173.5 x 328 mm)


24.3 lbs (11.0 kg)

Item Condition

Item Condition

Onkyo Factory Refurbished

Buying a Onkyo Factory Refurbished product is a great way to get "as-new" products at a considerable savings. Every product has been thoroughly tested, repaired (if necessary), cleaned and otherwise renewed to original condition. Next it’s repackaged in a new box with all original accessories included. When you consider that a factory-renewed Onkyo product undergoes such close scrutiny for defects and workmanship, you might actually be buying something that is in many ways better than new. And for your piece of mind and protection, your purchase is covered by a full 1 year parts and labor warranty valid at any authorized Onkyo repair center (you can look-up locations online here or call 201-785-2600)

Onkyo, like all electronics manufactures, receives products returned for various reasons. In 2011 consumers returned 17 billion dollars in electronics globally, of which less than 5% were found to be defective! Once a product has been opened it must be resold as refurbished and can’t be resold as new again. The history and reason why a product was returned is not provided to us, thus we can’t provide any additional details regarding its past. All products are processed by Onkyo certified technicians, where they are fully tested, repaired (only if necessary), and retested again to ensure the highest quality control. Each unit must pass a complete battery of test before it can be titled a "Onkyo Factory Refurbished" product.

All units are Cosmetically in Mint Condition (graded a 9 or higher on a scale of 1-10) unless otherwise stated. Very minor signs of wear (light surface scuffs or minor scratches) may be present, although most units show little or no signs of any usage. We DO NOT sell products that are cosmetically damaged (cracked displays, broken knobs, heavy scratches, or physically abused) unless noted in the description. Unfortunately, we can’t provide actual photos of each unit or pick the best one for anyone, as they are all randomly chosen from our factory sealed boxes.




Extended Warranties

Extended warranties

Get extra protection for your ONKYO TX-NR616 7.2-Ch THX Certified Network A/V Receiver with a comprehensive service plan


2 Year Plan gives you a TOTAL of 2 years warranty on the item

3 Year Plan gives you a TOTAL of 3 years warranty on the item

5 Year Plan gives you a TOTAL of 5 years warranty on the item



Average Customer Rating: (1 Review) Write a Review (requires login)

Onkyo TX-NR616

Reviewer: A viewer from Indiana, USA
This is a really nice unit. Crank the sound and it is so clear. I had an older model (TX-SR601). Wanted to get a newer unit with HDMI and inter connectivity with my home network.

Love the dlna. I can turn on my android tablet and listen to pandora or my own music files off my tablet.

This should last me another 10 years easy. My previous 601 was a refurb purchase and no problems at all, so I didn't have any queasiness about purchasing this refurbished 616.

The bass on this is much better than my 601. I don't have to turn my subwoofer up as much for the bass to really hit hard.

Great bargain at this price!
2 of 2 people found this review helpful. Do you? yes no  Certified buyer
