Engineered with proprietary technology and crafted with premium materials for timeless style, CINEMA 30 redefines cinematic sound for superior home theater systems.
CLICK HERE TO VIEW OWNERS MANUAL
- 11-channel amplifier
- 140 watts per channel into 8 ohms (20-20,000 Hz) at 0.05% THD, with 2 channels driven
- Marantz's Hyper Dynamic Amplifier Modules (HDAM) offer exquisite detail and dynamic range while reducing noise
- Dolby®, DTS®, and Auro-3D® surround sound decoding
- Dolby Atmos® and DTS:X processing for use with in-ceiling or "height" speakers for more enveloping home theater sound
- Dolby Atmos Height Virtualization and DTS Virtual:X create three-dimensional effects without height speakers
- IMAX® Enhanced reproduces the full dynamic range of specially encoded IMAX soundtracks from compatible sources
- analog-to-HDMI video conversion
- Audyssey speaker calibration and system optimization includes:
- MultEQ® XT32 auto setup and room calibration delivers balanced, dynamic sound with enhanced surround performance
- Dynamic Volume anticipates loud sounds to keep volume levels even
- Dynamic EQ improves dialogue, bass response, and surround channel levels at lower volumes
- Sub EQ HT provides individual calibration for four subwoofers, for even bass response throughout the room
- Low Frequency Containment reduces the amount of bass that bleeds into other rooms
- Audyssey MultEQ Editor app for further audio customization (paid app; not included)
- optional Dirac Live room calibration and bass management
- requires purchase of separate license from Dirac
- requires separate PC or Mac and a third-party USB microphone (all sold separately)
Achieve the Best Sound Possible
Dirac Live is a professional room acoustic solution that enables you to optimize your sound systems and reduce unwanted effects introduced by the room. Utilizing purpose-built audio algorithms, this world-class software is now available as an upgrade with CINEMA 30.
Sound For What You See
Listen and watch differently with the new Marantz CINEMA series. With artisanal craftsmanship, inspired design, and 70 years of innovation. This is cinematic sound, redefined. That means sound that’s better than the theaters, to reveal entertainment the way it’s meant to be heard. Bring home the sound of cinema.
High Power & Low Distortion
Each channel is rated at 140W with 0.05% THD, making both powerful dynamics and subtle detail a reality.
11 Channels & Countless Configurations
Though 11 amplifier channels are built in, CINEMA 30 can process up to 13.4 channels, making the perfect speaker layout for your room easy to achieve.
No Compromise Engineering
HiFi performance technologies like HDAM SA-2 and more elevate the CINEMA 30 to performance levels seldom found in an AVR.
Sound Master Tuned & Calibrated for You
Powerful calibration and tuning tools are included, enabling you to get the best performance from your system.
Highly Customizable
Thoughtfully curated connectivity options, myriad speaker configurations, and room calibration capability allow you to make CINEMA 30 your own.
Timeless Yet Modern Style
Excellence is heard and seen. CINEMA 30 is meticulously crafted in Japan with authentic materials in a modern style, befitting its rich heritage and stunning performance.
Complete Compatibility
Seven HDMI inputs, plus digital, analog, and phono inputs – even analog video plus loudspeaker and pre-amp outputs – ensure connectivity to virtually any components you have.
Specifications
Specifications
Amplification | |
Number Of Channels | 11 |
Stereo RMS Power (watts) | 140 |
THD in Stereo | 0.05% |
Frequency Bandwidth (stereo) | 20-20k Hz |
Minimum Impedance L/R | 4 ohms |
Minimum Impedance Center | 4 ohms |
Minimum Impedance Surround | 4 ohms |
Amplifier Class | AB |
General Features | |
Bluetooth | Built-in |
Apple AirPlay | AirPlay 2 |
Alexa-compatible | Yes |
Google Assistant-compatible | Yes |
Chromecast built-in | No |
DTS Play-Fi | No |
App Remote Control | Yes |
Built-in Radio Tuner | AM/FM |
On-Screen Display | Thru HDMI |
Room Correction | Audyssey MultEQ XT32, DiracLive (optional) |
Multi-room Audio/Video | |
Powered Multi-room Audio Output | Yes |
Preamp Multi-room Audio Output | Yes |
Multi-room HDMI Output | Yes |
Total Number of Zones | 3 |
Playback from Digital Audio Inputs | Yes |
Playback from Streaming Sources | Yes |
Surround Processing | |
Dolby Digital | DD, TrueHD, DD+ |
Dolby Atmos | Yes |
Dolby Atmos Height Virtualization | Yes |
DTS | DTS, HD, HDMA, 96/24 |
DTS:X | Pro |
DTS Virtual:X | Yes |
High-res Audio Playback | |
From Network | Yes |
From USB Thumb Drive (USB-A) | Yes |
From Computer (USB-B) | No |
Inputs | |
Audio-Video Inputs | 7 |
Number of HDMI Inputs | 7 |
Component Video Inputs | 1 |
Audio-only Inputs | 3 |
Phono Input | 1 |
Optical Digital Inputs | 2 |
Coaxial Digital Inputs | 2 |
Multi-Channel Analog Input | No |
Ethernet Port | Yes |
USB Connections | Y |
Outputs | |
HDMI Monitor Outputs | 3 |
Component Video Monitor Outputs | None |
Optical Digital Outputs | None |
Coaxial Digital Outputs | None |
Subwoofer Outputs | 4 |
Discrete Subwoofer Outputs | Yes |
Multi-channel Preamp Output | Yes |
Main Speaker Output Pairs | 1 |
Speaker Terminals | Binding Posts |
HDMI Features | |
HDMI Version | 2.1 |
VRR (Variable Refresh Rate) | Yes |
ALLM (Auto Low Latency Mode) | Yes |
4K/120Hz-Capable Inputs | 7 |
Audio Return Channel | eARC supported |
Video Upscaling | To 4K and 8K |
HDR (High Dynamic Range) Support | |
HDR10 | Yes |
HDR10+ | Yes |
HLG | Yes |
Dolby Vision | Yes |
Other Info | |
DAC Bit Depth | 32-bit |
DAC Sample Rate | 192 kHz |
FM Sensitivity | 12.8 dBf |
Multibrand Remote Control | Yes |
Learning Remote | No |
Removable Power Cord | IEC 2-prong |
Supports Wireless Rear Speakers | No |
Width (inches) | 17.375 |
Height (inches) | 7.4375 |
Depth (inches) | 18.5625 |
Weight (pounds) | 42.8 |
