From easy Bluetooth® wireless streaming to the heart-pounding thrills of Dolby Atmos® and DTS:X® soundtracks, the TX-SR494 deepensenjoyment of daily life with great sound and smart features. Seven channels of high-current power give you freedom to choose a speakerlayout that suits. Dolby Atmos Height Virtualizer* or DTS Virtual:X® place sound overhead or behind if you don’t want height or surroundspeakers and both Dolby Surround® and DTS Neural:X® are on board. Rear surrounds, bi-amped front speakers, or Powered Zone B audioare also an option. AccuEQ with subwoofer EQ and AccuReflexTM for 5.2.2-ch Dolby Atmos-enabled systems clarify sound in any space.As the heart of your home theater, the TX-SR494 has HDMI® terminals supporting HDR and 4K/60p video, while the GUI with OSD overHDMI, Zone B pre-/line-out, and Vocal Enhancer function make this receiver a joy to use as well as hear. *Enabled with a future firmware update.
CLICK HERE TO DOWNLOAD OWNERS MANUAL
Take Classic is a no-compromise collection of high-tech components-satellites, subwoofer and center channel- with all our best stuff packed inside great looking high-gloss black finish.
| Amplification | |
| Number Of Channels | 7 |
| Stereo RMS Power (watts) | 80 |
| THD in Stereo | 0.08% |
| Frequency Bandwidth (stereo) | 20-20k Hz |
| Minimum Impedance L/R | 4 ohms |
| Minimum Impedance Center | 4 ohms |
| Minimum Impedance Surround | 4 ohms |
| General Features | |
| Internet-ready | No |
| Bluetooth | Built-in |
| Apple AirPlay | No |
| Alexa-compatible | No |
| Google Assistant-compatible | No |
| Chromecast built-in | No |
| DTS Play-Fi | No |
| App Remote Control | No |
| USB port for iPod/iPhone | No |
| FM Sensitivity | Not Given |
| HD Radio Tuner | No |
| On-Screen Display | Thru HDMI |
| Auto Speaker Calibration | AccuEQ |
| Plays Copy-protected 4K | Yes |
| HDR-compatible | HDR10, Dolby Vision, HLG |
| HDMI Standby Pass-through | Yes |
| 4K Video Upscaling | Yes |
| HDMI to HDMI Upconversion | Yes |
| DLNA Certified | |
| MHL-compatible | No |
| Multibrand Remote Control | No |
| Learning Remote | No |
| LCD Remote | |
| Width (inches) | 17-1/8 |
| Height (inches) | 6-5/16 |
| Depth (inches) | 13-7/16 |
| Weight (pounds) | 18.1 |
| Multi-room Audio/Video | |
| Powered Multi-room Audio Output | No |
| Preamp Multi-room Audio Output | No |
| Multi-room HDMI Output | No |
| Playback from Digital Audio Inputs | No |
| Playback from Streaming Sources | No |
| Surround Processing | |
| Dolby Digital | DD, TrueHD, DD+, |
| Dolby Atmos | Yes |
| DTS | DTS, HD, HDMA, ES, 96/24 |
| DTS:X | Yes |
| Inputs & Outputs | |
| Phono Input | No |
| Audio-Video Inputs | 4 |
| Audio-only Inputs | 4 |
| Component Video Inputs | None |
| Component Video Monitor Outputs | None |
| Optical Digital Inputs | 1 |
| Coaxial Digital Inputs | 1 |
| Optical Digital Outputs | None |
| Coaxial Digital Outputs | None |
| HDMI Inputs | 4 |
| HDMI Monitor Outputs | 1 |
| Subwoofer Outputs | 2 |
| Discrete Subwoofer Outputs | No |
| Multi-Channel Analog Input | No |
| Multi-channel Preamp Output | No |
| Main Speaker Output Pairs | 1 |
| Main Speaker Terminals | Posts, Clips |
| Ethernet Port | 1 |
| USB Connections | Firmware updates only |
| Removable Power Cord | No |
| Specifications | Sat | Center | Sub |
| System Type | Magnetically Shielded Bass Reflex with Rear Firing Port | Magnetically Shielded Bass Reflex with Dual Front Firing Ports | Bass Reflex with Front Firing Port |
| Frequency Response (+/- 3 dB) | 115Hz-20KHz | 110Hz-20KHz | 33Hz-150Hz +/- 3dB |
| Tweeter | ¾-inch (19 mm) Hyperbolic™ aluminum-dome tweeter | ¾-inch (19 mm) Hyperbolic™ aluminum-dome tweeter | N/A |
| Woofer | 3-inch (7.6 cm) poly-titanium | 3-inch (7.6 cm) poly-titanium | 8” (20 cm) IM Cone with Patented Ribbed Elliptical Surround |
| Crossover Point | 2.9 kHz | 2.9 kHz | N/A |
| Efficiency (Room) | 89 dB | 89 dB | N/A |
| Impedance | 8-ohm compatible | 8-ohm compatible | N/A |
| Maximum Power Handling | 100 Watts | 100 Watts | N/A |
| Recommended Amplifier Power | 20 - 100 Watts RMS (Continous) | 20 - 100 Watts RMS (Continous) | N/A |
| Dimensions HxWxD | 6 7/8 x 4 1/8 x 4 1/8 | 4 1/8 x 10 1/4 x 4 1/8 | 12 5/8 x 12 5/8 x 12 5/8 (add 2 1/16” for feet) |
| Weight | 2.9 lb | 3.2 lb | 19.7 lbs |
| Inputs | Mini 5-Way Binding Posts | Mini 5-Way Binding Posts | N/A |
| Mounting Options | Built-in keyhole slot and threaded insert (1/4” - 20 TPI) | Built-in keyhole slot and threaded insert (1/4” - 20 TPI) | N/A |
| Amplifier Power Output | N/A | N/A | 200 Watts |
| Variable Phase Control | N/A | N/A | 0°, 180° |
| Variable Low Pass Filter | N/A | N/A | 40Hz-150Hz @ 18dB/octave |
| Inputs | N/A | N/A | Line In/Sub In & Speaker Level In |
| Power Mode Switch | N/A | N/A | On/Auto/Off |
