Description
Description
Indulge yourself in 5.2.2ch surround sound created by Dolby Atmos® or DTS:X, and even without height or surround speakers, you can still experience similar effects by Dolby Atmos Height Virtualizer and DTS Virtual:X. Enjoy superior images with Ultra HD, HDR10, HLG, and Dolby Vision™ pass through and support for HDCP 2.3. You can also stream songs from various sources via Wi-Fi, Bluetooth®, DTS Play-Fi, SONOS system, and Apple AirPlay 2. Other highlights include Powered Zone 2 feature with a dedicated DAC, Personal Preset buttons, and 2 HDMI outputs
CLICK HERE TO DOWNLOAD OWNERS MANUAL
Dolby Atmos®/Dolby Surround Upmixing
The VSX-LX104 is compatible with 5.2.2ch configuration of the latest theater sound platform, Dolby Atmos®. You can reproduce object-oriented sound in smooth, curving movements, or the realistic three-dimensional movement overhead by the top speakers. Other audio codecs such as PCM and DSD can be upmixed using Dolby Surround for enjoying 3D surround sound.
DTS:X®/DTS Neural:X Upmixing
DTS:X is the next-generation audio codec from DTS that leverages object-based audio to enable new immersive and interactive audio experiences. Since DTS:X can automatically adapt the audio to the existing channels and speaker system, no specific speaker layout is required. Experience an immersive soundscape with incredibly rich and life-like audio. Other audio codecs such as PCM and DSD can be upmixed using DTS Neural:X for enjoying 3D surround sound.
Dolby Atmos Height Virtualization & DTS Virtual:X
When playing any Dolby format, engaging the Dolby Atmos Height Virtualizer enables a more immersive listening experience, creating a virtual surround and height effect from traditional speaker layouts without employing additional surround or height speakers.
With DTS Virtual:X, you can enjoy a three-dimensional immersive sound similar to DTS:X, without the need of height or rear speakers. The technology supports 2 to 7.1.4-channel input source, for delivery on 2 to 5.1 or even 7.1-channel speaker layout. DTS Virtual:X works with all DTS codecs, including DTS:X.
Personal Preset
Just press the Personal Preset button on the front panel for three seconds, and your current settings such as volume level and listening mode can be saved. Up to three presets can be registered and easily called up from the front panel button or the remote control.
Dialog Enhancement
With this unique mid-range sound control feature, you can make independent volume adjustments to the range including dialogs in films, with the up/down key on the remote control.
Next Generation Video Standard Ready
The VSX-LX104 supports pass-through for HDR10, HLG (Hybrid Log-Gamma), and Dolby Vision signals. By connecting a compatible source device, you can enjoy these latest video standards on a compatible display. What’s more, all HDMI terminals support 4K (60p/4:4:4/24-bit), Wide Color Gamut (BT.2020), and HDCP 2.3, so you have no problem when upgrading to new devices, and can also enjoy premium content such as 4K videos with digital copy protection.
MCACC Auto Room Tuning
Create the optimum acoustic environment with Pioneer’s MCACC (Multi-Channel Acoustic Calibration System), developed with the expertise of professional recording studios. With the custom microphone, the system automatically compensates for differences in speaker size, level and distance, and equalizes response.
Works with SONOS
By connecting the VSX-LX104 to Sonos Connect, you can play any music or audio source on your Sonos app. You can group the VSX-LX104 with other Sonos devices on the network, or use it independently. The AV receiver will automatically turn on and switch input as soon as you play music on your Sonos app.
Powered Zone 2 with Dedicated DAC
With the powered feature, the VSX-LX104 can directly drive speakers in another room, without the need for a separate amplifier. What’s more, the dedicated DAC for Zone 2 lets you listen to all digital audio sources.
Zone B Output for Wireless Headphones
The VSX-LX104 is equipped with Zone B audio output terminals for expanding the Main Zone sound. You can listen to the sound playing in the living room via wireless headphones.
Built-in Bluetooth® Wireless Technology
Stream songs from compatible devices with the built-in Bluetooth® Wireless Technology (ver. 4.2 + LE). The VSX-LX104 features A2DP/AVRCP profiles, with support for SBC/AAC codecs. With Wake on Play function, the AV receiver automatically wakes up and switches input when a Bluetooth source starts playing.
Apple AirPlay 2
Apple AirPlay 2 lets you effortlessly stream music or podcasts to speakers throughout your house using any Apple device or by asking Siri, and it all stays in perfect sync.
Specifications
Specifications
| Power | |
|
Amplifier Design
|
Direct Energy |
| 8 ohms, 1 kHz, THD 0.08 %, 2ch Driven FTC | 80W+80W |
| 4 OHM Speaker | Yes |
| Channels | 7.2 |
| Power Output: Watts per Channel (1kHz,10%THD@6ohm 1ch Driven) | 170 W/ch |
| Estimated Power Consumption/Network Standby off | 460 W/0.1 W |
|
Handheld and Internet
|
|
|
AirPlay
|
Apple AirPlay 2 |
| Internet Radio | TuneIn Radio |
| FlareConnect™ for Multi-room Audio | Yes |
| Amazon Music, Pandora ® , Spotify, TIDAL, and Deezer Hi-Fi Music- | Yes |
| Streaming Audio From PC/Network | Yes |
| iOS/Android Remote Control APP | Pioneer Control App |
| DTS Play-Fi with Pioneer Music Control App | Yes |
|
Decoders & Formats
|
|
|
Digital Core DSP Engine
|
Digital Quad-Core 32-bit DSP (Cirrus Logic) |
| Audio Processing | 7.1 |
| IMAX Enhanced | Yes |
| Dolby Atmos Height Virtualizer | Yes |
| Dolby Digital Plus | Yes |
| DTS-HD Master Audio | Yes |
| DTS Virtual:X | Yes |
| Audio DACs | 384 kHz/32-bit D/A Conversion with AK4458 (AKM) |
| Music File Playback | 192 kHz/24-bit ALAC, AIFF, FLAC, WAV Via USB |
| Dolby Atmos | Yes |
| Dolby TrueHD | Yes |
| DTS:X | Yes |
| DTS Neural:X | Yes |
| HDMI SACD Transfer | |
|
Soundfield Calibration
|
|
|
MCACC
|
Yes |
| Phase Control | Yes |
| EQ Type | LR SYMMETRY EQ |
| Auto Subwoofer Crossover | Yes |
| MCACC Memory | 1 |
| EQ Bands | 9-Band |
| Distance Adjustment | 0.1 feet |
|
Listening Modes
|
|
|
Auto Surround
|
Yes |
| Advanced Surround | 10+1 |
| Stream Direct | Yes (Direct, Pure Direct) |
| Front Stage Surround Advance | Yes |
|
Audio Features
|
|
|
Dialog Enhancement
|
Yes |
| DSD Music File | Yes |
| Sound Delay (Lip Sync) | Yes |
| Advanced Sound Retriever | Yes (2ch) |
| Tone Control | Multi |
| Bi-Amp | Yes |
|
Video Processing
|
|
|
4K Ultra HD Pass-Through
|
Ultra HD Pass-through with HDCP 2.3 (4K/60p/4:4:4/24-bit, 4K/24p/4:4:4/36-bit, 4K/60p/4:2:0/36-bit) |
| 3-D Ready | Yes |
| HDMI Standby Through | Yes with Input Switch / Last Memory |
| Dolby Vision Compatible | Yes |
| HDMI x.v. Color | Yes |
| 4K Ultra HD Video Scaler | Yes (1080p to 4K) |
| Audio Return Channel | Yes |
| HDR | HDR10, HLG and BT.2020 Wide Color Gamut Signal Pass-through |
| HDMI 36-bit Deep Color | Yes |
|
Connectivity
|
|
|
HDMI Input / Output
|
6In (Rear) / 2 Out |
| Bluetooth Built-In | Bluetooth® Wireless Technology (Version: 4.2, Profile: A2DP 1.2/AVRCP 1.3, Codec: SBC/AAC) Built-in |
| Ethernet Input | Yes |
| Digital Audio Inputs / Output | 2 In (Optical 1, Coaxial 1) |
| Headphone Output | Yes |
| Phono Input | Yes |
| Wi-Fi Built-In | Dual Band (5 GHz/2.4 GHz) Wi-Fi® Built-in |
| USB Terminal | Front and Rear |
| Analog Audio Inputs / Output | 6 in / 0 out |
| Pre-Amp Output | 0.2 Ch |
| Front A/V Inputs | USB / 3.5mm stereo mini jack |
| AM/FM Presets | AM/FM Tuner 40 Presets |
|
Installation
|
|
|
On-Screen Display
|
User-Friendly GUI with System |
| Powered Zone output | Zone2 |
| Zone 2 Sources | All Audio Sources |
| RS-232C | Yes |
| Multi-Zone On-Screen Display | Yes |
| Function Rename | Yes |
| Personal Preset | Yes |
| Versatile Speaker Configuration | Speaker 9ch Out (FRONT, CENTER,SURROUND, SURROUND BACK/HEIGHT/Bi-AMP, ZONE 2) |
| Auto Power Down | Yes |
| Multi-Room and Source Output | ZONE B Line Out |
| 12 Volt Trigger (Assignable) | A |
| IR Serial Remote In/Out | 1 In |
| FL Dimmer | Yes |
| Remote | Yes |
| Sleep Timer | Yes |
|
Dimensions
|
|
|
W x H x D (inches)
|
17-1/8 x 6-13/16 x 14-9/16 inches (435 x 173 x 370.5 mm) |
| Weight | 26.5 lbs. (12.0 kg) |
Item Condition
Item Condition
Buying a Pioneer Factory Refurbished product is a great way to get "as-new" products at a considerable savings. Every product has been thoroughly tested, repaired (if necessary), cleaned and otherwise renewed to original condition. Next it’s repackaged with accessories included. When you consider that a factory-renewed Pioneer product undergoes such close scrutiny for defects and workmanship, you might actually be buying something that is in many ways better than new. And for your piece of mind and protection, your purchase is covered by a full 1 year parts and labor warranty valid at any authorized Pioneer repair center (you can look-up locations online here or call 844-679-5350)
Pioneer, like all electronics manufactures, receives products returned for various reasons. In 2011 consumers returned 17 billion dollars in electronics globally, of which less than 5% were found to be defective! Once a product has been opened it must be resold as refurbished and can’t be resold as new again. The history and reason why a product was returned is not provided to us, thus we can’t provide any additional details regarding its past. All products are processed by Pioneer certified technicians, where they are fully tested, repaired (only if necessary), and retested again to ensure the highest quality control. Each unit must pass a complete battery of test before it can be titled a "Pioneer Factory Refurbished" product.
Minor signs of wear (light surface scuffs or minor scratches) may be present. We DO NOT sell products that are cosmetically damaged (cracked displays, broken knobs, heavy scratches, or physically abused). Unfortunately, we can’t provide actual photos of each unit or pick the best one for anyone, as they are all randomly chosen from our factory sealed boxes.b
